The ActivPanel 10 Premium comes with a choice of Android, Windows, or ChromeOS compute devices, allowing you to work in the environment that best suits the needs of your school. It includes two seats of Promethean ActivSuite, a versatile software suite that brings popular Promethean apps together in a single, easy-to-use toolbar - accessible on any Windows, macOS, or ChromeOS computer, whether at or away from the panel.
Intelligent interactive display
• Stunning visuals with optical bonding, QLED, and FALD.
• Touch-enabled Picture-in-Picture to interact with two sources at once.
Free yourself
• Move freely in the classroom with the ActivPen 2, no longer tied to the panel.
• Control presentations and highlight content from anywhere in the room.
Secure by design and built to last
• Support sustainability and reduce energy use with local dimming technology.
• Save costs by upgrading only the compute device, not the whole panel.
DISPLAY
Screen Size and Resolution: 75" 4K; UHD (3840 x 2160 @ 60 Hz)
Backlight Technology: QLED - High Density Direct LED Backlight
Full-Array Local Dimming: Yes
Screen Type: TFT LCD
Blue Light Reduction: Yes
Optical Bonded Glass: Yes
Aspect Ratio: 16:9
Display Area: 75": 1652 x 930 mm (65 x 36.6 in)
Display Colours: 1.07 Billion (10-bit)
LCD Viewing Angle 178°
LCD Response Time: 8 ms
LCD Refresh Rate (Panel): 60 Hz
LED Lifespan: 50,000 hours
Contrast Ratio Dynamic: up to 16,500:1
Contrast Ratio Static: up to 900,000:1
Typical Max. Brightness: 75": 880 cd/m²
Ambient Light Sensor: Yes
Glass Hardness: 9H (pencil) , 7 (Mohs)
Glass Type: Heat tempered
Glass Thickness: 3.2 mm
Glass Coating: Anti-Glare, Anti-Fingerprint, Anti-Smudge
INTERACTIVITY
Vellum Touch Technology: Yes
Continuous Touch Points: 50
Resolution: 32768 x 32768 px
Touch Response Time: 3 ms
Touch Accuracy: <1 mm
Scan Rate: 500 Hz
Gestures and Edge Swipes: Windows® supported
Unique Pen IDs: 3
Palm Erase: Yes
Palm Rejection: Yes
Writing-hand Palm Rejection: Yes
Pens Included: 2 x Passive battery-less pens, 1 x Activ pen
Integrated Wireless Active Pen Charger: Yes
Active Pen Features: Air Mouse, Pressure Sensitive Hand Writing, Red Dot Highlighter, Pagination Control
Pen Holder: Integrated full-length pen tray and side pockets
Pen Tip Diameter: 3 mm
Pen Eraser Diameter: 7 mm
Touch-enabled PiP: Yes
Compatibility: Windows® 10 and 11; macOS® Ventura 13 and Sonoma 14; Linux® Ubuntu 22.04 to 24.04 LTS; ChromeOS™; Android 14
AUDIO
Integrated Soundbar: 2 x 25 W + 20 W Subwoofer
Integrated Microphone: 8 Mic Array
CONNECTIVITY
OPS Slot: 1
HDMI In (Rear): 2 x 2.1
Display Port: 1 x 1.4
USB-A (Rear): 3 x 3.2 Gen 1
USB-A (Rear): 1 x 2.0
USB-B (Touch, Rear): 3 x 3.0
USB-C (Rear): 1 x 3.2 Gen 1 (100 W Power Delivery)
USB-A (Front): 1 x 3.2 Gen 1
USB-C (Front): 1 x 3.2 Gen 1 (65 W Power Delivery)
USB-A (Top): 1 x 3.0
USB-C (Top): 1 x 3.0
USB-C Out: 1 x 3.0
HDMI Out: 1 x 2.0
LAN In (RJ45): 10/100/1000
LAN Out (RJ45): 10/100/1000
Wake-on-LAN: Yes
S/PDIF: Optical
Audio Out (3.5 mm): 1
Serial (RS232): 1
COMPUTING
NO built-in Operating System. Secure by Design
Requires external PC/Notebok or insert OPS to run any software or application.
Compatible Promethean Devices : OPS-A, OPS-M and Chromebox
